Bi-Thermostatic
Bimetallic Steam Trap

From the historical point of view, the bithermostatic steam trap (Bitherm patent) has been the most recent and cutting-edge design brought into the market, providing the basis for intelligent steam traps.

It has a balanced pressure valve, whose needle is placed in the low speed flow area, what reduces erosion and extends its life reducing maintenance costs. It has an external adjustment mechanism, which allows adjusting the condensate discharge temperature while the trap is running, thus the user can easily modify the conditions of condensate evacuation or customizes the steam trap without interrupting the steam service. It also includes strainer and connector for monitoring system.

bi-thermostatic-infography

Body made of forged steel.
Internals coated by Titanium Nitride.

Range of application: up to 215 bar and 540 ºC.

bi-thermostatic-infography

Body made of carbon steel, alloy steel or stainless steel. Internals are in stainless steel.

Range of application: up to 45 bar and 400 ºC.

SmartWatchWeb

This is the most innovative, outstanding, and efficient steam trap ever designed (Bitherm patent).

Its extraordinary high efficiency has allowed users to reduce 15% to 30% steam consumption which means a great impact concerning environmental protection and sustainable growth (reduction of GHG emissions).

Unlike others, BiTherm is the most complete intelligent stem trap in the market, including inbuilt connections up to 4 sensors (ultrasound, temperature, pressure, and backpressure) what means complete capability for monitoring and diagnosis

Its inbuilt connectors for sensors (even pressure and back pressure sensors) simplify installation and maintenance.

Components


  1. Outlet pressure sensor

    Condensate back pressure sensor

  2. External adjustment mechanism

    To set the operation temperature whiles the steam trap is running


  1. SmartWatch electronic device

    Including U&T sensors

  2. Input & output lock valves
  3. Steam inlet connection
  4. Inlet pressure sensor

    Steam pressure sensor

intelligent-steam-trap

SmartWatchWeb

SmartWatchWeb is an advanced and powerful remote monitoring system which allows immediate detection of internal and external gas and steam leaks in steam traps and valves. It also facilitates and increases the energy efficiency of steam and condensate networks as well as reduces GHG emissions. This cutting edge technology has given to conventional traps, and valves, intelligence to become smart devices. It was designed taking into consideration performances such as high scalability and availability, and allow new sensors being installed in the coming future by using the same infrastructure.

This innovative system has been developed and patented by BiTherm, and can integrate up to 4 different sensors: ultrasound, temperature, pressure and presence of toxic and explosive gases. The company has carried out technical breakthroughs in the industry with products such as intelligent steam traps, and the Intensive Maintenance concept, which are pioneering this field. Backed up by its Research and Development Department, we keep on pushing forward in order to anticipate the needs of the market.

SmartWatchWeb interface uses the most robust technologies available in the market. It was programmed under three main parameters: being powerful, intuitive and with a very graphical interface making it be user friendly.

The system is safe, robust, powerful, reliable, and it allows to implement the Intensive Maintenance, which have been developed with the aim to provide highly efficient solutions allowing sustainable projects, respecting the environment and fighting against climate change which means a rational and intelligent use of energy, increasing facilities’ safety, reducing GHG emissions, and maintenance costs.

SmartWatchWeb has a wide range of applications in the industry: automatic shut-off valves, pressure, relief and safety valves, steam traps, process equipment, flanges, pipeline accessories,… and has the widest variety of data transmission options (wired, wireless or clustered).

intelligent-steam-trap

SmartWatchWeb

SmartWatchWeb is an advanced and powerful remote monitoring system which allows immediate detection of internal and external gas and steam leaks in steam traps and valves. It also facilitates and increases the energy efficiency of steam and condensate networks as well as reduces GHG emissions. This cutting edge technology has given to conventional traps, and valves, intelligence to become smart devices. It was designed taking into consideration performances such as high scalability and availability, and allow new sensors being installed in the coming future by using the same infrastructure.

This innovative system has been developed and patented by BiTherm, and can integrate up to 4 different sensors: ultrasound, temperature, pressure and presence of toxic and explosive gases. The company has carried out technical breakthroughs in the industry with products such as intelligent steam traps, and the Intensive Maintenance concept, which are pioneering this field. Backed up by its Research and Development Department, we keep on pushing forward in order to anticipate the needs of the market.

SmartWatchWeb interface uses the most robust technologies available in the market. It was programmed under three main parameters: being powerful, intuitive and with a very graphical interface making it be user friendly.

The system is safe, robust, powerful, reliable, and it allows to implement the Intensive Maintenance, which have been developed with the aim to provide highly efficient solutions allowing sustainable projects, respecting the environment and fighting against climate change which means a rational and intelligent use of energy, increasing facilities’ safety, reducing GHG emissions, and maintenance costs.

SmartWatchWeb has a wide range of applications in the industry: automatic shut-off valves, pressure, relief and safety valves, steam traps, process equipment, flanges, pipeline accessories,… and has the widest variety of data transmission options (wired, wireless or clustered).

Magnus

This is a family of thermostatic-thermodynamic bimetallic steam traps specially designed for very high flow capacities. The steam trap is composed by a variable number of bimetallic elements inbuilt in the body that allows each steam trap to be tailored to any user particular needs.

Among their interesting characteristics can be highlighted its robustness, long lasting life, high energy efficiency, robust, adjustable discharge temperature and low maintenance cost.

SmartWatchWeb

Wired Architecture

This is the most powerful monitoring architecture due to the following aspects:

Complete monitoring of steam traps including the three characteristic parameters, which affect steam traps operation (Ultrasound, Temperature, and Backpressure). Wireless only includes Ultrasound and Temperature due to battery life.

Reduced installation costs: up to 64 monitored elements linked to the same cable, which includes power supply and data transmissions.

Reliability: Interferences free (piping, structures, obstacles, buildings, etc).

Sample collection: Sampling rate is not limited by battery life (real time).

Reduction of maintenance cost: Neither replacement of batteries nor maintenance of radio transmitters.

Easy commissioning: High qualified wireless staff is not required.

Device Name

Device Name

Device Name

Main Applications

Monitoring of large number of elements

Huge amount or high density population of elements to be monitored; e.g. refineries or petrochemical plants where there are hundreds or thousands of steam traps per plant.

High sampling rate

Such as safety applications; e.g. monitoring of PRV which handle toxic or explosive gases.

Avoid interference

Monitoring of elements near the ground or surrounded by lots of piping or metallic structures that could interfere wireless transmissions.

Monitoring toxic or explosive gases

Using the same system, i.e. integration of energy saving and safety applications.

SmartWatchWeb

Wireless Architecture

This option requires considering the following design aspects:

Partial monitoring of steam traps: It only includes two parameters (Ultrasound, Temperature) due to battery life.

Installation costs: Besides one wireless transmitter per element, wired Access Points need to be considered (It is important to highlight that wireless architectures are based on access points, which require to be powered by wire and optical fiber for data transmission).

Reliability: Study of environment (piping, structures, obstacles, buildings, etc).

Sample collection: Sampling rate affects battery life.

Maintenance cost: Replacement of batteries and maintenance of radio transmitters to be considered.

Commissioning: High qualified wireless staff is required.

Device Name

MAIN APPLICATIONS

Small amount or low density population of elements to be monitored; e.g. isolated elements on high positions over the ground; e.g. PRV on top of towers, etc.

Complementary Product

Trap Valve Stations

BiTherm trap valve station, TVS, offers an inlet isolation piston valve, outlet isolation piston valve, by-pass valve, testing valve, universal flange for connecting any kind of steam trap and the SmartWatch connection, all merged in a single body.

One of the main advantages is that constitutes a very compact design, reducing installation space, saving welds, and allow replacing steam traps in a very easy way.

trap-valve
trap-valve
manifold

Complementary Product

Steam and Condensate Manifolds

In large industries using steam, long distribution lines for steam and condensate service provide a constant source of maintenance hazards and energy wastage through numerous leakages.

BiTherm steam manifolds are designed to solve such typical problems (vertical installation). Fabricated headers to supply steam, or collect condensate, avoiding sources of leakage. Moreover, this also impulses the aesthetics of a well-designed plant; and eliminates continuous monetary losses due to energy wastage.

BiTherm steam and condensate manifolds are made from forged steel to suit various operating conditions. These are available in configurations of 4, 8 or 12 ways. Integral piston valves of seatless design will ensure that leakages across seat are eliminated totally.

PISTON VALVES HAVE TWO CLEAR ADVANTAGES

  • The valve stem and sealing surfaces are protected from dirt.
  • Piston sliding, without turns, between the rings preventing dirt from damaging the sealing surfaces, ensuring long duration.
